RV2 Curved Series
Affichage LED de scène flexible et créatif incurvé
Série flexible RV2
Affichage LED de scène flexible et créatif incurvé
Dimension: 500mm*500mm*84mm
Pas de pixels : 2.6mm, 2.9mm
Applications: Live Music, Business Activities, Beauty Contest, Stage Activities
7680Hz rafraîchissement élevé
Triple Anti-collision
Tool - free
Extended Power Cable
Front & Rear maintenance
Flexible Splicing
-
Vidéo
-
Solution unique
-
Personnages
-
Projet de référence
-
Spécification
-
Série flexible RV2
Comment chercher une solution?
Choisissez les bons produits d'affichage LED pour vos projets
Obtenez votre devis
Sélectionnez les produits LED les plus rentables
Dernière catégorie de produit
Téléchargez la liste des dernières catégories de produits mpled
Triple Anti-collision
The enhanced PCB design ensures robust attachment of LED lamps to the board providing excellent resistance against impacts, shakes, hits, and collisions during transportation, installation, and dismantling.
Precise ARC (Optionnel)
Adjustable mounting angles: 0°, +/- 3.5°, +/- 7.5°
Shape the Curve, Command the Stage
RV2 flexible displays enhance creative freedom with a precision gear transmission mechanism, allowing easy adjustments of each panel from -30° to +30 in 1.25° increments. This enables the effortless creation of seamless curves, S-shapes, and cylinders starting. When paired with RV2 panels, these displays open up even more possibilities for innovative stage design
Mini Corner, One Is Enough
Built for tight indoor stage spaces, features a distinctive rounded-corner design that pairs perfectly with RV2 panels-and seamlessly integrates with Right-angle Panel and Flexible Displays for limitless creative configurations
De plein air – Bright and Stable Displays
RV2 outdoor displays feature a brightness of 5000 nits, with standard 16-bit high grayscale levels and 7680Hz high refresh rate. Achieves a maximum contrast ratio of 8000:1, ensuring a clear and stable display even under intense outdoor lighting conditions.
Application
Live Music, Business Activities, Beauty Contest, Stage Activities
Accessoires
Fournisseur mondial de solutions d'affichage LED
RV2-Power Supply Box
RV2-Power Supply
RV2-Video Processor
RV2-Receiving Card
Projet de référence
Paramètres du produit
| Paramètre | P2.6 | P2.9 |
| Pas de pixels |
2.6mm | 2.9mm |
| Configuration des LED | CMS1415 | CMS1415 |
| Densité de pixels (points/㎡) | 147,456 points/㎡ | 112,896 points/㎡ |
| Indice IP | IP65 | |
| Luminosité (nits) | 4500-5000lentes réglables | |
| Taille du module (mm) | 250×250mm | |
| Taille de l'armoire (mm) | 500x500x84mm | |
| Cabinet weight (Historique médical) | 6.94Historique médical / 12.26Historique médical | |
| Angle de vision (H/V) | Horizontal: 160°, Verticale: 140° | |
| Échelle de gris (peu) | 14-16peu | |
| Max.. / Sont le pouvoir | 640/192 (W/m²) | |
| Rafraîchir | 3840Hz ~ 7680Hz | |
| Tension d'entrée (V) | 110V/220V (Optionnel), 50/60Hz | |
| Environnement de travail | Temperature -20℃~60℃, 10%-90% Humidité | |
| Durée de vie | Lifespan ≥ 100000H, MTBF ≥ 50000H | |
Quel service MPLED peut vous offrir?
Solution unique: Avec 20+ équipe d'experts de plusieurs années,MPLED fournit la solution la plus complète pour votre projet, ce qui facilite votre entreprise,plus professionnel et compétitif.
Picture & Video Visualization
Dessin CAO et simulation 3D
100% conception clientpersonnaliser
Ingénieur d'usine Assistance sur site
7Assistance technique x24h
Équipe d'installation internationale
Contactez-nous
Sujet : Affichage LED de scène flexible et créatif incurvé
FAQ
What is a rental curved LED display used for?
Rental curved LED displays are mainly used for stages, événements en direct, exposition, Salons professionnels, and immersive spaces, where creative shapes and strong visual impact are required.
What curved shapes can this LED display create?
The display supports concave, convex, S-shaped, wave-shaped, and cylindrical configurations, making it suitable for a wide range of creative designs.
Can the curved LED screen be used as a flat screen?
Oui. The cabinets support both flat and curved installation, allowing flat and curved screens to be mixed in one setup for maximum flexibility.
Is the curved LED display suitable for both indoor and outdoor use?
Oui. Indoor and outdoor versions are available, with different brightness levels and IP ratings to match various application environments. For indoor events or stages, the RF series offers comfortable brightness of 800-1000nits and an IP43 protection level. Pour les applications extérieures, it offers stable performance: Haute luminosité (up to 5000nits) to ensure clear visuals IP65 super-protection for resisting harsh outdoor weather
Can the curved LED screen be hung or only ground-mounted?
The special hanging bar design supports safe and stable hanging installation, as well as ground stacking, depending on event requirements.
